2DIN car audio frame for Kia/Hyundai 188x100

0 downloads208 views0 quality score

Print this part

Use the part context as a starting point, then confirm geometry-dependent values in your slicer.

Files

1 hosted model file

STL

Material start

PETG

Saved part guidance

Strength start

20-30% infill for durability and flexibility

Saved part guidance

Orientation / supports

verify in slicer

Exact totals

Slice for grams + time

Model geometry and final settings determine both

Vehicle exposure

Cabin/interior use; avoid high-heat zones

Open the STL, 3MF, or OBJ model in your slicer before printing. Exact grams, time, and final support placement come from the actual slice. Test-fit and heat-check the part before installing it in a vehicle.

License & use

CC BY

Commercial use allowed

Attribution required

The file license permits commercial reuse, subject to any applicable attribution or share-alike terms. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

Standard 2DIN head unit size is 178x100, while Kia/Hyundai in some cars has the rectangular window for the unit of size 188x100. This frame was designed for Chinese Android-based head units, which have a 177mm x 100mm front panel and a 181.5mm x 104mm plastic "brim" (see photos). I have designed it to fit my Kia Cerato, but it should be good for other Kia and Hyundai cars with the same head unit window size. I recommend to use PETG for this print: it is both flexible and strong enough. Do not use PLA for car and outdoors prints, since it can be deformed on a heat. The brackets on the photo, which are used to mount the head unit to the car, are in another thing
