Adapter to fit the 6 Speed Allison Automatic Transmission to the Toyota Engine 22RE

0 downloads35 views0 quality score

Print this part

Use the part context as a starting point, then confirm geometry-dependent values in your slicer.

Files

Source link only

No hosted model files

Material start

PETG or ASA for durability and heat resistance

Saved part guidance

Strength start

20-30% infill for strength and moderate weight

Saved part guidance

Orientation / supports

verify in slicer

Exact totals

Slice for grams + time

Model geometry and final settings determine both

Vehicle exposure

Engine-bay exposure — use rated material or OEM

Download the model at its source, then confirm the format is supported by your slicer. Exact grams, time, and final support placement come from the actual slice. Test-fit and heat-check the part before installing it in a vehicle.

Download at source

License & use

CC BY-NC

Link-only

Attribution required

Files stay with the original publisher; this catalog entry does not grant hosting or resale rights. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

This is an adapter to fit my 6 Speed Allison Automatic Transmission (http://www.thingiverse.com/thing:1094616) to the Toyota 4 Cylinder Engine 22RE made by ericthepoolboy (http://www.thingiverse.com/thing:644933). My automatic transmission wasn't really made for this engine, but as some of you might now "ericthepoolboy" made an awesome working model of that engine and the manual transmission for it, and I thought that the people that printed that engine could print also my automatic transmission as an optional add-on. Is at the original scale and is easily swappable so you can change from manual to automatic transmission very quickly and without modifying anything to their existing engine nor transmission. This adapter screws on the case of the automatic transmission, with the front cover in the middle, so you need 9 screws with 10mm long, 1.5mm of diameter. After that, all you have to do is screw the bell housing to the adapter using the same screws you use to secure the manual transmission.

Compatible Cars

Toyota (all models)

Published Jun 26, 2026Updated Aug 11, 2026

Originally published on thingiverse.com by Interlink Knight (InterlinkKnight) · License: CC BY-NC
