Alfa Romeo GTV6 Headlight Alignment Cup

0 downloads57 views0 quality score

Print this part

Use the part context as a starting point, then confirm geometry-dependent values in your slicer.

Files

Source link only

No hosted model files

Material start

PETG, ASA, or PC-ABS blend for durability in outdoor conditions

Saved part guidance

Strength start

High infill (80-100%) for robustness

Saved part guidance

Orientation / supports

verify in slicer

Exact totals

Slice for grams + time

Model geometry and final settings determine both

Vehicle exposure

UV/weather exposure — ASA is the starting point

Download the model at its source, then confirm the format is supported by your slicer. Exact grams, time, and final support placement come from the actual slice. Test-fit and heat-check the part before installing it in a vehicle.

Download at source

License & use

CC BY-NC

Link-only

Attribution required

Files stay with the original publisher; this catalog entry does not grant hosting or resale rights. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

This is a headlight alignment cup/bracket/mount replacement I made for my 1985 Alfa GTV6. It works with the original screw and pulls/pushes the headlight into alignment based on how tight the screw is turned. Parts for these cars are becoming much more rare, so I'm attempting to duplicate what I can. More pictures of the real object coming soon. This is a direct clone of the shape and has no modifications or optimizations done to make it easier to print. As such it is very difficult to print. Also, due to being part of a car, make sure to print in a robust material. My original versions were made out of Taulman Bridge Nylon, but these days I am favoring a PC-ABS blend.
