CB Antenna Mount for Jeep Wrangler JK

0 downloads192 views0 quality score

Print this part

Use the part context as a starting point, then confirm geometry-dependent values in your slicer.

Files

Source link only

No hosted model files

Material start

PETG or ASA for durability in outdoor conditions

Saved part guidance

Strength start

20-30% infill for strength, 1.6-2 mm walls

Saved part guidance

Orientation / supports

verify in slicer

Exact totals

Slice for grams + time

Model geometry and final settings determine both

Vehicle exposure

High cabin heat — validate PETG or choose ASA/ABS

Download the model at its source, then confirm the format is supported by your slicer. Exact grams, time, and final support placement come from the actual slice. Test-fit and heat-check the part before installing it in a vehicle.

Download at source

License & use

CC BY

Commercial use allowed

Attribution required

The file license permits commercial reuse, subject to any applicable attribution or share-alike terms. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

This is a bracket I made on CNC plasma for a 1/2" CB antenna stud to mount the antenna on a Garvin Adventure Rack's windshield hoop. It is held on by a 5/16" U-bolt. The windshield is tilted at 25 degrees, so cutting this part and putting a 90 degree bend in it puts the antenna vertical. I cut this out of a piece of 3" x 8" x 3/16" mild steel, overkill for this application. 1/8" would be fine.
