iPhone 6+ (with case) Holder - Hyundai i30 - image

Files (2)

Hyundai_CD_Mount_V3.stl

STL

110.3 KB

Hyundai_Phone_Holder_V2.stl

STL

708.6 KB

Print guidance estimate

Slicer data required

Print cost & setup estimate

Setup guidance plus saved or slicer-confirmed filament, cost, and time. Model file size is never treated as printable volume.

2 model files

Typical selected file

Slice required

Choose the needed variant and slice it; source file size is not printable volume.

Material cost

Slice required

Use the slicer's filament total; STL/3MF byte size is not a cost input.

Print time

Slice required

Slice with the recommended material, infill, orientation, and supports.

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 25%	100% solid	Recommendation
Hyundai_CD_Mount_V3.stl	Mount / bracket	110.3 KB STL	Slice file	Slice file	Slice file	Ensure the phone holder section is properly aligned with the CD slot mount
Hyundai_Phone_Holder_V2.stl	Mount / bracket	708.6 KB STL	Slice file	Slice file	Slice file	Ensure the phone holder section is properly aligned with the CD slot mount

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Phone Mounts

iPhone 6+ (with case) Holder - Hyundai i30

0 downloads186 views0 quality score

Print this part

Check the available model and saved setup details before opening your slicer.

Files

2 hosted model files

STL

Material

PETG or ASA

Print time

Slice to calculate

Filament

Slice to calculate

Supports

verify in slicer

Infill

20-30% infill with 2-3 walls for durability

Difficulty

Not rated — inspect geometry

Vehicle heat

Cabin/interior use; avoid high-heat zones

Open the STL, 3MF, or OBJ model in your slicer before printing. Confirm orientation, supports, print time, filament use, and printer compatibility. Test-fit before installing it in a vehicle.

License & use

CC BY

Commercial use allowed

Attribution required

The file license permits commercial reuse, subject to any applicable attribution or share-alike terms. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

28-05-2019 - Hmmmmmm!! Trimming the cd slot section needs to be WAY more drastic - those damned CD sensors! OK, need a bit of a rethink, I'll post a new version when it's ready. Sorry.:( _________________________________________________________________________ 26-05-2019 - Rework No.2 Fits together great, bumps on the top not as effective as I expected, 2 versions of CD Slot mount now revised - one version - V3 - now, the previous caused my CD player to try sucking the holder in. Notched the sides now so it shouldn't hit the sensors. Bobble on the top slightly too high (and forward) so the whole thing sits a bit too proud. Updated the files but I'll be manually fettling my print until it works - then I'll cross check against the.STL. THEN (and only then) will I print in PET-G and finally remove the WIP flag. Thanks. _________________________________________________________________________ 25-05-2019 - Rework No.1 Reshaped the phone holder section for ease of print, added nubs to locate it better (maybe). Changed CD Mount slot angle by 5 degrees - bottom of phone sits away from radio a bit. Extended the CD slot part - and knocked up another. Both have centralised raised sections to hopefully locate it a bit better in the radio cut-out. These changes may make an OK holder quite a good one. Again, I'll update and change when I know if it works. Pics of the printed part and fitment once it's sorted. _________________________________________________________________________ 25-05-2019 Quick edit - It does work, kinda, but i'm going to rework the rear to give better support and flatten it for ease of print. To be uploaded later. _________________________________________________________________________ A quick(ish) remix of seajseven's holder - the 3 parts whacked together (because supports cause me no problems) and with a slot-in 'CD' section to delicately hold it in the Hyundai i30 GD (Elantra for our US cousins). It's based on a phone with a slim case fitted - because I can't be bothered to take it off all the time. It's a WIP and is being printed in PLA right now to see if it fits. I might have the angle reversed....... In the morning I will pop it off the printer and test it out - adjust as necessary - and report back. Enjoy (the wait)...
