Mechanical/Functional

Nissan Leaf Battery Cap

0 downloads72 views0 quality score

Print this part

Use the part context as a starting point, then confirm geometry-dependent values in your slicer.

Files

3 hosted model files

STL

Material start

PETG or ASA for durability and heat resistance

Saved part guidance

Strength start

20-30% infill for a balance between strength and weight

Saved part guidance

Orientation / supports

verify in slicer

Exact totals

Slice for grams + time

Model geometry and final settings determine both

Vehicle exposure

Cabin/interior use; avoid high-heat zones

Open the STL, 3MF, or OBJ model in your slicer before printing. Exact grams, time, and final support placement come from the actual slice. Test-fit and heat-check the part before installing it in a vehicle.

License & use

CC BY

Commercial use allowed

Attribution required

The file license permits commercial reuse, subject to any applicable attribution or share-alike terms. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

These are snap-on covers for Nissan Leaf battery cells. The large cover (works on positive and negative terminal) allows room for a M6 screw (I use hex-head cap screws) and a side hole for a 10-12AWG terminal wire spade. The spade terminal also helps hold the cap in place once the screw is tightened. The small cover (works on center sense terminal) allows room for a M4 screw and a side hole for a 14-16AWG terminal wire spade. I've also included a small cap for the center sense terminal if you don't need access to it. This fits when there is no screw inserted into this terminal. I have adjusted the dimensions for what works well for my printer, so I hope it works well for others too. The terminals aren't quite square so it only will only fit on in two orientations (single orientation for the black terminal due to the alignment tab on the battery). If it doesn't fit properly you should be able to adjust the size a few percent up or down to get it to work.
