Jeep JK 3.8L (2007-2011) Air Compressor Bracket

0 downloads213 views0 quality score

Print this part

Use the part context as a starting point, then confirm geometry-dependent values in your slicer.

Files

Source link only

No hosted model files

Material start

PETG or ASA

Saved part guidance

Strength start

20-30% infill with 2-3 walls for strength and durability

Saved part guidance

Orientation / supports

verify in slicer

Exact totals

Slice for grams + time

Model geometry and final settings determine both

Vehicle exposure

Cabin/interior use; avoid high-heat zones

Download the model at its source, then confirm the format is supported by your slicer. Exact grams, time, and final support placement come from the actual slice. Test-fit and heat-check the part before installing it in a vehicle.

Download at source

License & use

CC BY

Commercial use allowed

Attribution required

Safety/IP review

The file license permits commercial reuse, subject to any applicable attribution or share-alike terms. License status does not verify vehicle fitment, OEM rights, design patents, or safety.

Shared by

3DPrintedCarPart

Verified

Description

This is a bracket for mounting a Viair clone type compressor in a Jeep JK (3.8L). It mounts on two bolts on the brake booster underneath the master cylinder in a manner similar to the Dominion Offroad or Synergy compressor mounts. The tray bends and holes on this are specifically sized for a TJM compressor, so it is not a universal fit, but I included the solidpart files so you can edit it. I cut this out of 14 gauge steel on a CNC plasma, hence the tray bends and gusset, which I MIG welded on. If you have thicker stock around, I'm sure you can skip them.
